Silent Angel's HiFi Streaming Solution

Silent Angel's solution is born for music lovers who want to build the high-quality HiFi network and pursue the purest audio quality possible.

Our Unique Position

We provide quality components for residential HiFi streaming networks, including:

Audio network switch (Wondering why network switches improve audio performance? See here)
Music streamer/transporter
Linear power supply
Music server

Audio Network Switch

Bonn Series

Learn more

Music Streamers (Transporter)

Munich and Bremen Series

Learn more

Linear Power Supply

Forester Series

Learn more

Music Server

Rhein Series

Learn more

Our Determination

We understand that achieving the ultimate sound quality is not an easy goal. Therefore, we poured in dedicate effort and passion to optimize everything from hardware, mechanical, to software design.

Each of Silent Angel's products were created to pursue superior audio quality by improving many details without compromise.

Why Do You Need to Look at Our Solution?

With Silent Angel's components, you can:

Build up a digital audio network
Acquire more audio sources
Enjoy existing HiFi systems with pleasant experience

How Do You Obtain More Audio Sources?

Here are the applications that you can set up and the audio sources you can obtain for your existing HiFi systems.

Roon infrastructure.
High-resolution streaming services (such as Qobuz, Spotify, ...and more.)
Playing music collections from local or network shared storage.

Roon infrastructure

High-resolution streaming services (such as Qobuz, Spotify,...and more.)

Playing music collections from local or network shared storage.

Audio Network Switch - Bonn Series

	NX	N8 Pro	N8	N16 LPS
Product	8-Port Audiophile Grade Network Switch	8-Port Audiophile Grade Network Switch	8-Port Audio Grade Network Switch	16-Port Audio Grade Network Switch With Two Zones
Ethernet	8-Port Gigabit Ethernet Gold plated ports Spacing out ports physically	8-Port Gigabit Ethernet Gold plated ports Spacing out ports physically	8-Port Gigabit Ethernet	16-Port Gigabit Ethernet consists of 2 individual switch module. Each Zone has 8 ports.
Noise Reduction by EMI Absorber
TCXO Highly Accurate Clock
Power	Radar Grade internal switching power AC 100-240V	Radar Grade internal switching power AC 100-240V	Medical Grade power adaptor DC 5V power input	Built-in linear power supply (Powered by Forester technology) AC 100-240V
Power for Clock Circuit	Hybrid Power V2 + Three Stages Noise Filter	Hybrid Power V1 + One Stage Noise Filter	Switching Power	Linear Power
Power for Switch Circuit	Hybrid Power V2 + Three Stages Noise Filter	Hybrid Power V1 + One Stage Noise Filter	Switching Power + Two Stages Noise Filter	Linear Power + Two Stages Noise Filter
Power Source Upgrade	by F2 Linear Power Supply	by F2 Linear Power Supply	by F1 or F2 Linear Power Supply	N/A
Clock Input	Direct Clock 25MHz	General Clock 10MHz	N/A	N/A
Advanced Options	Additional DC 12V power jack for upgrade Gold-plated ground connector LED indicator on/off switch Class-leading clock receiving module reserved for external clock input	Additional DC 12V power jack for upgrade Gold-plated ground connector LED indicator on/off switch Class-leading clock receiving module reserved for external clock input (option)
Vibration Damping Isolators	Large Stainless Steel	Standard	N/A	N/A
Chassis	Double-layer, aluminum alloy with galvanized steel	Galvanized steel	Galvanized steel	Galvanized steel
Dimension (W x H x D)	17.29 x 2.49 x 9.95 inch 439 x 63 x 250 mm	17.37 x 1.74 x 6.89 inch 441 x 44 x 175 mm	6.09 x 1.03 x 3.35 inch 154.5 x 26 x 85 mm	17.37 x 1.74 x 6.54 inch 441 x 44.1 x 166 mm
	Learn more	Learn more	Learn more	Learn more

Music Server - Rhein Z1 and Rhein Z1 Plus

	Rhein Z1	Rhein Z1 Plus
Launch Date	2019	February 2023
CPU	Intel Quad-core CPU J3160	Intel Quad-core CPU J6413
RAM	8GB / 16GB	16GB / 32GB
Storage	0TB / 1TB / 2TB SATA SSD	250GB / 4TB NVMe SSD
Word Clock	Regular Clock	Highly Accurate TCXO Clock
External Clock Input Port	N/A	25MHz x 1
Ethernet	1GbE x 1	1GbE x 2
Expansion USB Port	USB 3.0 x 2 USB 2.0 x 1	USB 3.1 x 2 USB 2.0 x 1
USB Audio Output	First Generation USB Audio Output with Noise Reduction	Second Generation USB Audio Output with Improved Noise Reduction Enhancement
Type-C	N/A	x 1
Multiple Audio Players Output Simultaneously	x 2	x 10
PCM	Up to 768KHz 32-Bit	Up to 768KHz 32-Bit
DSD	Playback: up to DSD256 Roon DSP Transcoding: Not supported	Playback: up to DSD512 Roon DSP Transcoding: up to DSD256
Power Source Upgrade	by F2 Linear Power Supply	by F2 Linear Power Supply
Dimension (W x H x D)	7.87 x 2.56 x 7.87 Inch 200 x 65 x 200 mm	7.87 x 2.56 x 7.87 Inch 200 x 65 x 200 mm
	Learn more	Learn more

Music Streamer/ Transporter - Munich and Bremen Series

	M1	M1T	B2	B1	B1T
Product	Network Music Streamer	Network Music Transporter	Network Music Streamer For HiFi Entry	Network Music Streamer For HiFi Entry	Network Music Transporter For HiFi Entry
Applications	Hi-res music streaming services Roon Ready Player Local or LAN music via SMB (NAS), DLNA Digital & Analog Audio Outputs Play DSD files MQA-supported Headphone	Hi-res music streaming services Roon Ready Player Local or LAN music via SMB (NAS), DLNA Digital Audio Outputs (to DAC) Play DSD files MQA-supported	Music streaming services Digital & Analog Audio Outputs DLNA renderer (player) Headphone	Music streaming services Digital & Analog Audio Outputs DLNA renderer (player) Headphone	Music streaming services Digital Audio Output (to DAC) DLNA renderer (player)
MQA			N/A	N/A	N/A
PCM	USB: 768kHz AES/EBU: 384kHz	USB: 768kHz AES/EBU: 384kHz	up to 192kHz	up to 192kHz	up to 192kHz
DSD	USB: DSD 256 AES/EBU: DSD 128	USB: DSD 256 AES/EBU: DSD 128	N/A	N/A	N/A
Streaming Music	Qobuz: 192kHz HIGHRESAUDIO: 192kHz	Qobuz: 192kHz HIGHRESAUDIO: 192kHz	Amazon Music: 44.1KHz TIDAL: TIDAL HiFi Qobuz: 192kHz	Amazon Music: 44.1KHz TIDAL: TIDAL HiFi Qobuz: 192kHz	Amazon Music: 44.1KHz TIDAL: TIDAL HiFi Qobuz: 192kHz
Operating System	VitOS	VitOS	VitOS Lite	VitOS Lite	VitOS Lite
CPU	4 Cores 1.5GHz ARM Cortex-A72	4 Cores 1.5GHz ARM Cortex-A72	2 Cores 1.2GHz ARM Cortex-A72	2 Cores 1.2GHz ARM Cortex-A72	2 Cores 1.2GHz ARM Cortex-A72
DRAM	2GB / 4GB / 8GB	2GB / 4GB / 8GB	128 MB	128 MB	128 MB
Flash	32 GB High Speed	32 GB High Speed	128 MB	128 MB	128 MB
LAN	Gigabit Ethernet (max 1000Mbps)	Gigabit Ethernet (max 1000Mbps)	Fast Ethernet (max 100Mbps)	Fast Ethernet (max 100Mbps)	Fast Ethernet (max 100Mbps)
BlueTooth	N/A	N/A	BlueTooth 5.0 with EDR and BLE	BlueTooth 5.0 with EDR and BLE	BlueTooth 5.0 with EDR and BLE
Wi-Fi	N/A	N/A	802.11 a/b/g/n/ac 2.4GHz, 5GHz	802.11 a/b/g/n/ac 2.4GHz, 5GHz	802.11 a/b/g/n/ac 2.4GHz, 5GHz
Wi-Fi Antenna	N/A	N/A	Internal Antenna	Directional Antenna	Directional Antenna
Digital Audio Outputs	AES/EBU Coaxial I2S USB Audio	AES/EBU Coaxial I2S USB Audio	AES/EBU Coaxial I2S	AES/EBU Coaxial I2S	AES/EBU Coaxial I2S
Analog Audio Outputs	RCA L+R 6.35mm Headphone Jack	N/A	RCA L+R 6.35mm Headphone Jack	RCA L+R 6.35mm Headphone Jack	N/A
Power Source Upgrade	by F1 Linear Power Supply	by F1 Linear Power Supply	N/A	by F1 Linear Power Supply	by F1 Linear Power Supply
Dimension (W x H x D)	6.11 x 1.99 x 4.34 inch 155 x 50.4 x 110 mm	6.11 x 1.99 x 4.34 inch 155 x 50.4 x 110 mm	12.13 x 1.89 x 6.78 inch 308 x 48 x 172 mm	6.11 x 1.99 x 4.34 inch 155 x 50.4 x 110 mm	6.11 x 1.99 x 4.34 inch 155 x 50.4 x 110 mm
	Learn more	Learn more	Learn more	Learn more	Learn more

Linear Power Supply- Forester Series

Forester F1, Linear Power Supply With Dual 5V DC Outputs

Employs two DC 5V-2A outputs, compatible with these models:

Bonn N8, Munich M1, Bremen B1, Munich M1T.

Learn more

Forester F2, Linear Power Supply With Multiple 12V & 5V DC Outputs

Employs 12V-3A , 12V-1A, 5V-2A , and 5V-1A (DC jack or USB) outputs, compatible with these models:

5V DC output: Bonn N8, Munich M1, Bremen B1, Munich M1T
12V DC output: Bonn NX, Bonn N8 Pro, Rhein Z1.

Learn more

Product Selection Guide 2022 H1

Download
